Product Overview
The AKSA AC1410 is a heavy-duty diesel generating set built for dependable high-capacity standby and prime power use across commercial, industrial, infrastructure, construction, data centre, agricultural, and critical backup power applications. It delivers 1410 kVA / 1128 kW standby power and 1280 kVA / 1024 kW prime power, making it suitable for sites that require large-scale 50Hz, 3-phase electrical supply.
Powered by a Cummins KTA50-G3 diesel engine, the AC1410 uses a 16-cylinder, 50.3-litre, V-type diesel engine running at 1500rpm. The engine is turbocharged and aftercooled, with direct fuel injection, electronic governor control, replaceable fuel, oil and dry element air filters, water cooling, radiator and fan assembly, starter battery system, and 12/24V DC starter and charge alternator system.
The generator is supplied with an ECO 43-2L/4 A alternator, offering brushless operation, stable voltage regulation, and reliable electrical output for high-capacity standby and prime power loads. The alternator system is designed to support dependable performance across commercial, industrial, and critical power installations.
Control and protection are handled through the generator control system, with monitoring for generator voltage, current, frequency, battery voltage, engine oil pressure, coolant temperature, running hours, operating status, alarms, and shutdown conditions. The AC1410 is available in open or canopy configuration depending on installation requirements.
Key features
- 1410 kVA / 1128 kW standby power
- 1280 kVA / 1024 kW prime power
- Cummins KTA50-G3 diesel engine
- 400/230V, 50Hz, 3-phase output
- 1500rpm engine speed
- 0.8 power factor
- 16-cylinder, 50.3-litre V-type diesel engine
- Turbocharged and aftercooled
- Water-cooled engine design
- Direct injection fuel system
- Electronic governor system
- ECO 43-2L/4 A alternator
- Brushless alternator design
- 12/24V DC starter and charge alternator system
- Replaceable fuel, oil, and dry element air filters
- Industrial exhaust silencer and steel bellows
- Open or canopy configuration
- Suitable for standby, prime, commercial, industrial, infrastructure, data centre, agricultural, and site power use
Technical summary
| Specification | Details |
|---|
| Manufacturer | AKSA Power Generation |
| Model | AC1410 |
| Fuel type | Diesel |
| Standby power | 1410 kVA / 1128 kW |
| Prime power | 1280 kVA / 1024 kW |
| Voltage | 400/230V |
| Frequency | 50Hz |
| Phase | 3 Phase |
| Power factor | 0.8 |
| Engine | Cummins KTA50-G3 |
| Engine speed | 1500rpm |
| Cylinders | 16 V-type |
| Displacement | 50.3 litres |
| Bore x stroke | 159 ? 159 mm |
| Compression ratio | 13.9:1 |
| Aspiration | Turbocharged and aftercooled |
| Cooling | Water cooled |
| Fuel system | Direct injection |
| Governor | Electronic |
| Starting system | 12/24V DC starter and charge alternator |
| Fuel consumption at full load | 261 L/hr |
| Fuel tank capacity | N/A |
| Oil capacity | 177 L |
| Coolant capacity | 340 L |
| Radiator cooling air | 1296 m?/min |
| Engine air intake | 96.3 m?/min |
| Exhaust gas flow | 231 m?/min |
| Alternator | ECO 43-2L/4 A |
| Alternator type | Brushless |
| Control panel | InteliGen NT |
