Product Overview
The AKSA APD110C is a diesel generating set built for dependable standby and prime power use across commercial, industrial, agricultural, construction, workshop, and backup power applications. It delivers 110 kVA / 88 kW standby power and 100 kVA / 80 kW prime power, making it suitable for sites that require stable 50Hz, 3-phase electrical supply.
Powered by a Cummins 6BT5.9-G2 diesel engine, the APD110C uses a 6-cylinder, 5.9-litre, turbocharged, water-cooled diesel engine running at 1500rpm. The engine features direct fuel injection, electronic governor control, dry-type air filtration, and a 24V DC electrical starting system.
The generator is supplied with an Aksa AK 480 alternator, offering brushless operation, Class H insulation, IP22 protection, SX460 AVR, and 1% voltage regulation. This helps provide stable output for general electrical loads and sensitive equipment used in standby and prime power applications.
Control and protection are handled by the DSE6120 control panel, which monitors generator voltage, current, frequency, battery voltage, engine oil pressure, coolant temperature, running hours, operating status, alarms, and shutdown conditions. The unit includes an integrated base fuel tank and is available in open or canopy configuration for different installation requirements.
Key features
- 110 kVA / 88 kW standby power
- 100 kVA / 80 kW prime power
- Cummins 6BT5.9-G2 diesel engine
- 400/231V, 50Hz, 3-phase output
- 1500rpm engine speed
- 0.8 power factor
- 6-cylinder, 5.9-litre diesel engine
- Turbocharged and water cooled
- Direct injection fuel system
- Electronic governor system
- Aksa AK 480 alternator
- Brushless alternator design
- SX460 automatic voltage regulator
- Class H alternator insulation
- IP22 alternator protection
- DSE6120 control panel
- Integrated base fuel tank
- Open or canopy configuration
- Suitable for standby, prime, commercial, agricultural, site, and industrial power use
Technical summary
| Specification | Details |
|---|
| Manufacturer | AKSA Power Generation |
| Model | APD110C |
| Fuel type | Diesel |
| Standby power | 110 kVA / 88 kW |
| Prime power | 100 kVA / 80 kW |
| Voltage | 400/231V |
| Frequency | 50Hz |
| Phase | 3 Phase |
| Power factor | 0.8 |
| Engine | Cummins 6BT5.9-G2 |
| Engine speed | 1500rpm |
| Cylinders | 6 in-line |
| Displacement | 5.9 litres |
| Aspiration | Turbocharged |
| Cooling | Water cooled |
| Governor | Electronic |
| Fuel consumption at full load | 22 L/hr |
| Fuel tank capacity | 195 L open type / 180 L canopy |
| Oil capacity | 13 L |
| Total coolant capacity | 35.9 L |
| Alternator | Aksa AK 480 |
| Alternator type | Brushless |
| AVR | SX460 |
| Voltage regulation | 1% |
| Insulation class | Class H |
| Protection class | IP22 |
| Controller | DSE6120 |
| Canopy | ACP 6A |
| Open set dimensions | 2150 ? 1000 ? 1469 mm |
| Open set dry weight | 1280 kg |
| Canopy dimensions | 2600 ? 1058 ? 1590 mm |
| Canopy dry weight | 1480 kg |
