BAUDOUIN APD1020BD Diesel Generator – 50Hz
The Aksa APD1020BD Diesel Generator is a 1020 kVA standby / 925 kVA prime power generator powered by a heavy-duty Baudouin 12M26G1000/5 diesel engine. Designed for reliable 400/231V, 50Hz three-phase power, it features electronic governing, Aksa AK 7740 brushless alternator technology, DSE 7320 AMF control, and robust construction for demanding commercial and industrial standby power applications.
Brand: BAUDOUIN
Aksa APD1020BD Diesel Generator ? 1020 kVA Standby Power
The Aksa APD1020BD Diesel Generator is a high-capacity diesel generating set designed for dependable standby and prime power applications. Powered by a heavy-duty Baudouin 12M26G1000/5 diesel engine, this generator provides reliable 400/231V, 50Hz three-phase power for industrial, commercial, and infrastructure environments.
With a standby rating of 1020 kVA / 816 kW and a prime rating of 925 kVA / 740 kW, the APD1020BD is suitable for demanding sites requiring high-output backup or prime power.
Key Features
- 1020 kVA standby power and 925 kVA prime power
- Powered by a Baudouin 12M26G1000/5 diesel engine
- Turbocharged and air-to-air aftercooled engine design
- 12-cylinder V-type engine configuration
- Electronic governor system for stable performance
- Aksa AK 7740 brushless alternator
- Class H insulation system
- MX341 Automatic Voltage Regulator
- Deep Sea Electronics DSE 7320 AMF control module
- Integrated fuel tank with 1600 litre capacity
- Available in open type or MS 88 sound attenuated canopy configuration
Engine Specifications
| Engine Brand | Baudouin |
|---|---|
| Engine Model | 12M26G1000/5 |
| Engine Configuration | 12-cylinder, V-type |
| Engine Speed | 1500 rpm |
| Aspiration & Cooling | Turbocharged and air-to-air aftercooled |
| Total Displacement | 31.8 litres |
| Bore x Stroke | 150 x 150 mm |
| Compression Ratio | 15.7:1 |
| Standby Engine Power | 902 kW / 1210 HP |
| Prime Engine Power | 820 kW / 1100 HP |
| Governor System | Electronic |
| Injection System | Direct injection |
| Fuel Pump Type | Mechanical |
| Operating Voltage | 24 Vdc |
| Battery Capacity | 2 x 143 Ah |
| Charge Alternator | 55 A |
| Oil Capacity | 114 litres |
| Coolant Capacity | 65 litres engine only / 139 litres total |
| Cooling Fan Air Flow | 840 m?/min |
| Fuel Consumption at 100% Prime Load | 195.5 L/hr |
| Fuel Consumption at 75% Prime Load | 146.5 L/hr |
| Fuel Consumption at 50% Prime Load | 100.8 L/hr |
| Block Heater | 2 x 3000 W |
Power Ratings
| Voltage | Standby Power | Prime Power | Standby Current |
|---|---|---|---|
| 400/231 V | 1020 kVA / 816 kW | 925 kVA / 740 kW | 1472.29 A |
| Frequency | 50 Hz | ||
| Phase | 3 Phase | ||
| Power Factor | 0.8 | ||
Alternator Specifications
| Alternator Manufacturer | Aksa |
|---|---|
| Alternator Model | AK 7740 |
| Alternator Power | 960 kVA |
| Design | Brushless |
| Voltage | 400 V |
| Frequency | 50 Hz |
| Phase | 3 Phase |
| AVR | MX341 |
| Voltage Regulation | ?1% |
| Insulation System | Class H |
| Protection | IP22 |
| Rated Power Factor | 0.8 |
| Alternator Weight | 2233 kg |
| Cooling Air | 130.8 m?/min |
Control System
The APD1020BD is equipped with an Auto Mains Failure control panel featuring the DSE 7320 control module. This control system monitors mains supply and generator operation, automatically starting and stopping the generating set when required.
- DSE 7320 Auto Mains Failure control module
- Microprocessor-based control system
- Main status and instrumentation display
- Menu navigation buttons
- Close mains and close generator buttons
- Status LEDs and alarm LEDs
- Static battery charger
- Fuses for control circuits
- Emergency stop push button
- Control panel mounted on generating set base frame or power module
Monitoring Functions
- Generator voltage monitoring
- Generator current monitoring
- Generator frequency monitoring
- Engine speed monitoring
- Engine oil pressure monitoring
- Coolant temperature monitoring
- Battery voltage monitoring
- Running hours display
- Mains supply monitoring
- Generator output and load monitoring
Protection Features
- Low oil pressure protection
- High coolant temperature protection
- Over speed and under speed protection
- Under/over generator voltage protection
- Under/over generator frequency protection
- Battery voltage warning
- Charge failure warning
- Fail to start protection
- Fail to stop warning
- Emergency stop shutdown
- Over current protection
- Electrical trip functions
Dimensions and Fuel Tank Capacity
| Open Type Length | 4200 mm |
|---|---|
| Open Type Width | 2204 mm |
| Open Type Height | 2226 mm |
| Open Type Fuel Tank Capacity | 1600 litres |
| Canopy Model | MS 88 |
| Canopy Width | 2260 mm |
| Canopy Height | 2539 mm |
| Canopy Fuel Tank Capacity | 1600 litres |
Standard Specifications
- Heavy-duty Baudouin diesel engine
- Water-cooled engine system
- Turbocharged and air-to-air aftercooled design
- Direct injection fuel system
- Mechanical fuel pump
- Electronic governor system
- 24V DC electrical system
- Dry type air filter
- Brushless Aksa alternator
- Integrated base frame fuel tank
- Control panel in sheet steel enclosure
- Corrosion-resistant pre-coated steel control panel surface
- Durable polyester composite powder-coated finish
Applications
The Aksa APD1020BD is suitable for large commercial buildings, industrial facilities, factories, data centres, hospitals, infrastructure sites, telecom facilities, utilities, construction sites, and emergency backup systems where dependable high-output diesel power is required.
Optional Equipment
- Fuel-water separator filter
- Oil heater
- Anti-condensation heater
- Oversized alternator
- PMG excitation and AVR
- Main line circuit breaker
- Galvanized canopy coating
- ISO container option
- Marine grade paint
- Automatic synchronising and power control system
- Multi-generator parallel system
- Parallel system with mains
- Transition synchronisation with mains
- Alarm output relays
- Earth fault protection
- Remote relay output
- Remote communication with modem
- Charge ammeter
- Three or four pole contactor transfer panel
- Three or four pole motor-operated circuit breaker
- Main fuel tank
- Automatic or manual fuel filling system
- Electrical or manual oil drain pump
- Low and high fuel level alarm
- Inlet and outlet motorized louvers
- Inlet and outlet acoustic baffles
- Maintenance tool kit
- 1500 / 3000 hours maintenance kit
- Residential silencer
- Spark arrester silencer
- Critical silencer
- Catalytic converter
The Aksa APD1020BD Diesel Generator is built for dependable high-capacity power generation, combining Baudouin diesel engine technology, Aksa AK 7740 alternator performance, DSE 7320 AMF control, and durable industrial construction for demanding standby and prime power applications.
