AKSA AC3000 diesel generator set rated at 2900 kVA / 2320 kW standby and 2625 kVA / 2100 kW Data Centre Continuous power. Powered by a Cummins QSK78-G9 diesel engine, this 400/231V, 50Hz, 3-phase generator is designed for critical backup and data centre power applications, with Stamford LV 804 S alternator, InteliGen NT control panel, electronic governing, and automatic synchronisation support.
Product Overview
The AKSA AC3000 is a high-capacity diesel generating set built for data centres, large commercial facilities, industrial sites, and critical standby power systems. It delivers 2900 kVA / 2320 kW standby power and 2625 kVA / 2100 kW Data Centre Continuous power at 400/231V, 50Hz, 3-phase output.
Powered by a Cummins QSK78-G9 diesel engine, the AC3000 uses an 18-cylinder V-type, 77.6-litre, turbocharged and aftercooled engine running at 1500rpm. The engine features direct fuel injection, electronic governor control, water cooling, 24V DC electrical system, and heavy-duty diesel performance for demanding emergency power applications.
The generator is paired with a Stamford LV 804 S alternator with Class H insulation, IP23 protection, 0.8 power factor, and ?0.5% voltage regulation. The InteliGen NT control panel supports MODBUS communication, automatic mains failure operation, synchronisation, power control, and multiple generator parallel operation.
Key features
- 2900 kVA / 2320 kW standby power
- 2625 kVA / 2100 kW Data Centre Continuous power
- Cummins QSK78-G9 diesel engine
- 18-cylinder V-type engine configuration
- 77.6-litre displacement
- Turbocharged and aftercooled engine
- 400/231V, 50Hz, 3-phase output
- 1500rpm engine speed
- 0.8 power factor
- Electronic governor system
- Direct injection fuel system
- Water-cooled diesel engine
- Stamford LV 804 S alternator
- Class H alternator insulation
- IP23 alternator protection
- InteliGen NT control panel
- MODBUS communication support
- Automatic synchronisation and power control
- Suitable for data centre, standby, emergency, commercial, and industrial power use
Technical summary
| Manufacturer | AKSA Power Generation |
| Model | AC3000 |
| Fuel type | Diesel |
| Standby power | 2900 kVA / 2320 kW |
| Data Centre Continuous power | 2625 kVA / 2100 kW |
| Voltage | 400/231V |
| Frequency | 50Hz |
| Phase | 3 Phase |
| Power factor | 0.8 |
| Engine | Cummins QSK78-G9 |
| Engine speed | 1500rpm |
| Cylinders | 18 cylinders, V-type |
| Displacement | 77.6 litres |
| Aspiration | Turbocharged and aftercooled |
| Cooling | Water cooled |
| Governor | Electronic |
| Fuel consumption at 100% load | 528 L/hr |
| Fuel consumption at 75% load | 406 L/hr |
| Fuel consumption at 50% load | 291 L/hr |
| Alternator | Stamford LV 804 S |
| Alternator type | Single bearing |
| Insulation class | Class H |
| Protection class | IP23 |
| Voltage regulation | ?0.5% |
| Control panel | InteliGen NT |
| Communication | MODBUS |
| Open generator dimensions | 11000 x 2800 x 3888 mm |
