Product Overview
The AKSA APD10P is a compact diesel generating set built for dependable standby and prime power use across residential backup, small commercial premises, farms, workshops, site cabins, and light-duty power applications. It delivers 10 kVA / 8 kW standby power and 9 kVA / 7.2 kW prime power, making it suitable for installations that require stable 400/230V, 50Hz, 3-phase electrical supply.
Powered by a Perkins 403A-11G1 diesel engine, the APD10P uses a 3-cylinder, 1.131-litre, naturally aspirated, water-cooled diesel engine running at 1500rpm. The engine features direct fuel injection, mechanical governor control, replaceable fuel, oil and dry element air filters, cooling radiator and fan, and a 12/24V DC starter and charge alternator system.
The generator is supplied with a brushless single-bearing alternator with revolving field design, 2/3 pitch stator, Class H insulation, self-excitation, self-regulation, and direct-drive centrifugal blower cooling. This helps provide stable output for compact standby and prime power loads.
The APD10P is available in open, canopy, soundproof canopy, and trailer configuration depending on installation requirements. The generator set is built as a compact, complete power unit with easy start, service-friendly access, and factory testing before delivery.
Key features
- 10 kVA / 8 kW standby power
- 9 kVA / 7.2 kW prime power
- Perkins 403A-11G1 diesel engine
- 400/230V, 50Hz, 3-phase output
- 1500rpm engine speed
- 0.8 power factor
- 3-cylinder, 1.131-litre diesel engine
- Naturally aspirated and water cooled
- Direct injection fuel system
- Mechanical governor system
- Brushless single-bearing alternator
- Self-excited and self-regulating alternator system
- Class H alternator insulation
- Integrated 32-litre fuel tank
- Compact generator set design
- Open, canopy, soundproof canopy, or trailer configuration
- Suitable for standby, prime, residential, small commercial, agricultural, workshop, and site power use
Technical summary
| Specification | Details |
|---|
| Manufacturer | AKSA Power Generation |
| Model | APD10P |
| Fuel type | Diesel |
| Standby power | 10 kVA / 8 kW |
| Prime power | 9 kVA / 7.2 kW |
| Voltage | 400/230V |
| Frequency | 50Hz |
| Phase | 3 Phase |
| Power factor | 0.8 |
| Engine | Perkins 403A-11G1 |
| Engine speed | 1500rpm |
| Engine power output | 9.5 kWm / 13 HP |
| Cylinders | 3 vertical in-line |
| Displacement | 1.131 litres |
| Bore x stroke | 77 ? 81 mm |
| Compression ratio | 23:1 |
| Aspiration | Naturally aspirated |
| Cooling | Water cooled |
| Fuel system | Direct injection |
| Governor | Mechanical |
| Starting system | 12/24V DC starter and charge alternator |
| Fuel consumption at full load | 2.6 L/hr |
| Fuel tank capacity | 32 L |
| Oil capacity | 4.9 L |
| Coolant capacity | 5.2 L |
| Radiator cooling air | 40.2 m?/min |
| Engine air intake | 0.7 m?/min |
| Exhaust gas flow | 1.8 m?/min |
| Alternator type | Brushless single bearing, revolving field |
| Stator | 2/3 pitch |
| Rotor | Single bearing, flexible disc |
| Exciter type | Self excited |
| Alternator cooling | Direct drive centrifugal blower fan |
| Insulation class | Class H |
| Temperature rise | 125 – 163?C continuous |
| AC waveform distortion | No load < 1.5%; non-distorting balanced linear load < 5% |
| Telephone influence factor | < 50 per NEMA MG1-22.43 |
| Telephone harmonic factor | < 2% |
| Configuration options | Open, canopy, soundproof canopy, or on-road trailer |
